Specification
Diamond: | SFL |
Cantilever: | Aluminium |
Transducer: | MC Stereo |
Magnet: | AlNiCo, nickel-plated |
Body: | Aluminium, blue anodized |
Connection: | 1/2″ – 4pin |
Vertical Tracking Angle: | 23° |
Weight: | 12g |
Tracking force: | 2,4g |
Output voltage: | 1.05mV @ 5cm/s |
Compliance: | 12μm/mN |
Frequency response: ±2dB: |
20 – 25‘000Hz 40 – 12‘500Hz |
Impedance: | 2×24Ω |
Recommended load: | 200 – 300Ω |
Nomenclature
HSD: | HiFi Stereo Diamond |
006: | Stylus tip radius in microns |
SFL: | Super Fine Line diamond shape |
